Product Description:
GCYFY(Loose tubestranding, Tiny tube, Dry water-blocking , PE sheath)
Standards:
YD/T1460-2006 Jetnetoptical cable for telecommunications and fiber unit
Technical Parameters(Typical Value):
Fiber Count | Structure | Diameter | Weight | Tensile(N) | Crush(N) | Bending Radius(mm) | |||
(mm) | (kg/km) | Long term | Short term | Long term | Short term | Static | Dynamic | ||
2-30 | 1+6 | 6. 6 | 34 | 0. 15G | 0. 5G | 150 | 450 | 10D | 20D |
32-36 | 1+6 | 6. 6 | 35 | 0. 15G | 0. 5G | 150 | 450 | 10D | 20D |
38-60 | 1+6 | 7. 0 | 39 | 0. 15G | 0. 5G | 150 | 450 | 10D | 20D |
62-72 | 1+6 | 7. 0 | 40 | 0. 15G | 0. 5G | 150 | 450 | 10D | 20D |
74-84 | 1+7 | 7. 5 | 46 | 0. 15G | 0. 5G | 150 | 450 | 10D | 20D |
86-96 | 1+8 | 8. 0 | 52 | 0. 15G | 0. 5G | 150 | 450 | 10D | 20D |
98-108 | 1+9 | 8. 5 | 58 | 0. 15G | 0. 5G | 150 | 450 | 10D | 20D |
110-120 | 1+10 | 9. 2 | 67 | 0. 15G | 0. 5G | 150 | 450 | 10D | 20D |
122-132 | 1+11 | 9. 7 | 74 | 0. 15G | 0. 5G | 150 | 450 | 10D | 20D |
134-144 | 1+12 | 9. 9 | 82 | 0. 15G | 0. 5G | 150 | 450 | 10D | 20D |
Note:
1.D refers to the cable diameter;
2.The relevant technical Parameters canbe adjusted according to the customer’s demands;
3.The design flame resistance,anti-rodent, termite resistant cable according to the customer’s demands.
